RGV-Rail Guided Vehicle

4 indicators: small footprint, wide application range, manpower saving, high efficiency

RGV: RGV is the abbreviation of Rail Guided Vehicle, which is also called rail shuttle. Rail guided vehicle can be used in all kinds of multiple depth storage warehouses, and the RGV aisle length can be customized.


With rail guided vehicle, storage capacity of whole warehouse can be increased, and there is no need for forklift to drive into aisle when operating, which means high safety performance. Since forklift will not enter into aisle, and the rgv rail guided vehicles run fast in the aisles, the operation efficiency of the wms system can be improved significantly.


  • Rgv-rail Guided Vehicle
  • Rgv-rail Guided Vehicle
  • Rgv-rail Guided Vehicle
  • Rgv-rail Guided Vehicle
  • Rgv-rail Guided Vehicle
  • Rgv-rail Guided Vehicle

Specification of RGV-Rail Guided Vehicle

RGV main parameters

Body dimension L*W*h

L592*W592*H240(mm)

Communication method

WLAN Wireless Local Area Network

Sorting parcel dimension L*W*h

L300*W200*H100(mm)

RGV weight

25.4 kg

Running direction

Four way running

lifting time

1.5s

Running speed

0~120m/min

Battery service time

8H

Positioning accuracy

±1mm

Loading capacity

3KG

Driving positioning

Photoelectric control

AGV control method

Auto/Manual

Power

48V,Lithium cell

Braking method

Motor deceleration, electromagnetic braking

Charging method

Automatic

E-stop braking

less than 15mm

Safety protection

Safe contact + e-stop buttons

Mechanical position adjusting on track

Steerable wheel×4

Unloading method

Roller conveying

Roller speed

10m/min with loading, 25m/min without loading


Lisen Automation, as a material handling system supplier, supplies rail guided vehicles with customized aisle length.



Advantages of RGV-Rail Guided Vehicle

  • Linear design, compact structure, small footprint, extremely space saving.

  • Wide application range, applicable for variety of goods of different sizes, shapes and natures, lower than 10KG, including very small and thin goods.

  • The running noise of the omnidirectional mobile robot is very little.

  • Low operation and maintenance cost of rail guided vehicle system, easily and safely operated.


Advantages of RGV-Rail Guided Vehicle

Application Industries of RGV-Rail Guided Vehicle


  • Small parcel e-commerce industry

  • Express industry

  • Post industry


Application Scenarios of RGV-Rail Guided Vehicle

Small parcel sorting at distribution points of small parcel e-commerce, Post and Express companies.
