Root and Fruit Sorter

The root and fruit weighing and packaging machine independently developed by Lisen Automation is a set of automatic system equipment integrating material handling, weighing and packaging. The equipment is composed of intelligent control system, feeding and conveying system, weighing and metering system, packaging and discharging system, and has the advantages of compact structure, convenient operation and accurate metering.


  • Root-and-Fruit-Sorter-1.jpg
  • Root-and-Fruit-Sorter-1.jpg

After setting the corresponding parameters in the control system, the supply staff only needs to dump the goods into the feeding frame, and the equipment automatically completes the processes of soil removal, screening, deliver, metering, packaging and labeling, so as to save manpower to the greatest extent, improve operation efficiency and help the enterprise achieve cost reduction and efficiency increase.


Parameter of Root and Fruit Sorter

No.

Items

Parameter

Remarks

1

Dimensions

L12.8m×W3.4m×H3.8m

Standard model

2

Weight

3000kg


3

Application

Potatoes, onions, oranges and other root fruits


4

Packable size

Potato Max. 100mm; Orange Max. 80mm


5

Packaging speed

20-35bags/min


6

Metering channel

12


7

Measurement range

0.5-5kg


8

Measurement accuracy

Error<0.4-0.8%


9

Packaging material

Net bag


10

Buckle material

Copper,aluminum wire


11

Voltage

380V


12

Power

5KW


13

Gas source

The minimum air pressure is 0.5MPa

Gas consumption 250 NL / min


Product features

  • Stable operation and simple operation

  • One machine can be used for multiple purposes to liberate labor

  • Compact structure, compact and convenient

  • Multi channel metering, high speed and accuracy

  • Module erection, rapid assembly and disassembly


Applicable scenario

The root and fruit weighing and packaging machine is suitable for food, supermarkets, e-commerce, logistics and other industries. It provides a one-stop solution for quantitative packaging of root and fruit such as potatoes, onions and oranges.


  • Farm

  • Fruit and vegetable distribution factory

  • Supermarket

  • Logistics warehouse

  • Rural cooperative

  • Restaurant

  • Fresh processing

  • Online retailers


Applicable products
